HT Part No. HT230417
Mfr. Part No. JS1APF-B-24V-FT
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Relay Type | Relay Power |
| Contact Voltage | 250VAC/30VDC |
| Packaging | TRAY |
| Mounting Type | THT |
| Coil Type | Non Latching |
| Operating Temperature | -40°C~+85°C |
| Series | JS |
| Width | 16.00mm |
| Keyword | relay power, guc rolesi, spst-no role, tek kontak role |
| Manufacturer | PANASONIC COMP. |
| Contact Form | SPST-NO (1 Form A) |
| Contact Current (Nom) | 10A |
| Coil Resistance | 1.60K Ohms |
| Coil Power | 360mW |
| Rohs | ROHS |
| Contact Current (Max) | N/A |
| Coil Voltage | 24VDC |
| Coil Current | 15mA |
| Length | 22.00mm |
| Height | 16.00mm |
| Number of Pins | 4 Pin |
