HT Part No. HT230476
Mfr. Part No. ALDP118W
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Contact Current (Nom) | 5A |
| Coil Power | 200mW |
| Length | 20.50mm |
| Height | 15.30mm |
| Manufacturer | PANASONIC COMP. |
| Width | 7.20mm |
| Keyword | relay power, guc rolesi, spst-no role, tek kontak role |
| Coil Type | Non Latching |
| Coil Voltage | 18VDC |
| Contact Voltage | 277VAC/30VDC |
| Coil Resistance | 1.62K Ohms |
| Mounting Type | THT |
| Series | ALDP |
| Contact Form | SPST-NO (1 Form A) |
| Coil Current | 11.10mA |
| Operating Temperature | -40°C~+85°C |
| Relay Type | Relay Power Slim |
| Contact Current (Max) | N/A |
| Rohs | ROHS |
| Packaging | TRAY |
| Number of Pins | 4 Pin |
