HT Part No. HT230486
Mfr. Part No. ALQ305A01
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Coil Voltage | 5VDC |
| Operating Temperature | -40°C~+85°C |
| Height | 15.60mm |
| Number of Pins | 4 Pin |
| Relay Type | Relay Power Small |
| Coil Resistance | 125 Ohms |
| Coil Power | 200mW |
| Length | 20.00mm |
| Mounting Type | THT |
| Contact Current (Nom) | 5A |
| Contact Current (Max) | 10A |
| Coil Current | 40mA |
| Coil Type | Non Latching |
| Width | 10.00mm |
| Rohs | ROHS |
| Keyword | panasonic relay, alq panasonic, alq relay, alq seri |
| Manufacturer | PANASONIC COMP. |
| Series | ALQ |
| Contact Form | SPST-NO (1 Form A) |
| Contact Voltage | 250VAC - Max |
| Packaging | TRAY |
