HT Part No. HT230487
Mfr. Part No. JW2SN-DC5V
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Coil Voltage | 5VDC |
| Contact Voltage | 250VAC/30VDC |
| Length | 28.60mm |
| Series | JW |
| Keyword | relay power, guc rolesi, 2 Form C role |
| Contact Form | DPDT (2 Form C) |
| Coil Type | Non Latching |
| Contact Current (Nom) | 5A |
| Rohs | ROHS |
| Packaging | TRAY |
| Manufacturer | PANASONIC COMP. |
| Contact Current (Max) | N/A |
| Coil Resistance | 47 Ohms |
| Coil Power | 530mW |
| Number of Pins | 8 Pin |
| Relay Type | Relay Power |
| Mounting Type | THT |
| Coil Current | 106mA |
| Operating Temperature | -40°C~+60°C |
| Width | 12.80mm |
| Height | 20.00mm |
