Phoenix Contact PSRmini PSR-MC40-3NO-1DO-24DC-SC Emergency Stop Safety Relay, 24V dc, Dual-Channel, 3 Safety Contacts

2700569 Phoenix Contact PSRmini PSR-MC40-3NO-1DO-24DC-SC Emergency Stop Safety Relay, 24V dc, Dual-Channel, 3 Safety Contacts
2700569
2700569
HT26023
HT26023
Safety Relays
Safety Relays
2700569 Phoenix Contact PSRmini PSR-MC40-3NO-1DO-24DC-SC Emergency Stop Safety Relay, 24V dc, Dual-Channel, 3 Safety ContactsPhoenix Contact
brand logo

HT Part No. HT26023

Mfr. Part No. 2700569

Manufacturer: Phoenix Contact

Technical Documents: Brochure-3c1b1c2a(datasheets) Declaration of Conformity-e25ffe90(datasheets) EC Certification-f47cc842(datasheets) Datasheet 2700569-18eee674(datasheets)

1 - In Stock pcs
Price:
£ 120.00
Units Per Unit Price
1 + £ 120.00
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Supply Voltage 24V dc
Number of Channels 2
Safety Contacts 3
Function Emergency Stop
Auxiliary Contacts 3
Reset Method Automatic & Manual
Range PSRmini
Safety Category ISO 13849-1 4
SIL IEC 61508 3
Terminal Type Screw
Configurable No
Series PSR-MC40-3NO-1DO-24DC-SC
Width 12.5mm
Depth 114.5mm
Length 112mm
3D Model https://www.traceparts.com/els/rs-components/en/api/viewer/3d?SupplierID=RS_COMPONENTS&PartNumber=8937701&DisplayLogo=False

More Information

Phoenix Contact PSRmini Safety Relay The PSRmini safety relays from Phoenix Contact are the most narrow safety relay on the market to provide proven safety thanks to force-guided contacts. The Innovative relay technology offers maximum safety and high switching loads up to 6 A.
The PSR-MS with a width of just 6 mm comes with 1 to 2 enabling paths, and the PSR-MC with a width of 12 mm comes with 2 to 3 enabling paths. They are available as a single or dual channel device suitable for monitoring emergency stops, safety doors and light curtains - as well as to control actuators. Features and Benefits • Compatible with all important signal transmitters and safety-relevant systems
• Screw and push-in spring connection
• Automatic reset, Automatic/Manual reset, Automatic/Manual/Monitored reset, Manual/Monitored reset options available
• Up to 70% space saved
• Easy and quick diagnosis given means shorter downtime
