VISHAY IHLP2020CZER4R7M11, INDUCTOR FIXED 4.7uH 5.49X5.18MM

ihlp2020czer4r7m11 VISHAY IHLP2020CZER4R7M11, INDUCTOR FIXED 4.7uH 5.49X5.18MM
IHLP2020CZER4R7M11
brand logo

HT Part No. HT194660

Mfr. Part No. IHLP2020CZER4R7M11

Manufacturer: VISHAY

Technical Documents: Datasheet(datasheets)

729 - In Stock pcs
Price:
£ 0.91
Units Per Unit Price
1 - 99 £ 0.91
100 - 499 £ 0.85
500 + £ 0.80
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type SMT
Rohs ROHS
Manufacturer VISHAY
Current Rating 5.2A
Packaging TAPE&REEL
Package / Case Non Standard
Technology Molded
DC Resistance (DCR) 54m Ohms
Series IHLP
Current - Saturation (Isat) N/A
Tolerance ±20%
Diameter N/A
Length 5.49mm
Pitch None
Shielding Shielded
Inductance 4.7uH
Applications General Purpose
Width 5.18mm
Height 3.00mm
Operation Temperature -55°C ~ +125°C

More Information

The VISHAY IHLP2020CZER4R7M11 is a compact, surface-mount power inductor designed for efficient power management in modern electronic circuits. This inductor boasts a 4.7 µH inductance value packed into a small 5.49 x 5.18 mm footprint. Its low DC resistance (DCR) minimises power loss, making it suitable for applications demanding high current handling.

Special Features and Benefits of the VISHAY IHLP2020CZER4R7M11, Surface-Mount Power Inductor

  • Small form factor for space-saving designs
  • High current capability
  • Low DC resistance for improved efficiency
  • Surface mount technology (SMT) for automated assembly
  • Enhanced system performance due to low power dissipation
  • Increased power density in compact designs
  • Improved thermal management
  • Simplified manufacturing processes

Application Versatility of the VISHAY IHLP2020CZER4R7M11, Surface-Mount Power Inductor

  • Power Supplies and Converters
  • DC-DC Converters
  • Automotive Electronics
  • Industrial Control Systems
  • Telecommunication Equipment
