Eaton DR1040‑150‑R Power Inductor Surface Mount Shielded Drum Core 15 µH 3.1 A

The Eaton DR1040-150-R is a compact, high-efficiency 15 µH shielded SMD power inductor, engineered for robust performance in demanding power systems. Designed with a ferrite drum core and wire-wound construction, this inductor provides reliable current handling and minimal energy loss, making it ideal for global B2B and technical applications.

Core Features of this shielded SMD Power Inductor

• Inductance: 15 µH ±30%, providing stable filtering and energy storage.
• Low DCR: Maximum 50 mΩ DC resistance (typical 37 mΩ), reducing power losses and improving efficiency.
• Compact Dimensions: 10.5 × 10.3 × 4 mm, suitable for tight PCB layouts.
• Operating Range: −40 °C to +125 °C, including temperature rise, ideal for harsh industrial environments.
• Shielded Design: Minimizes EMI in high-frequency and sensitive circuits.
• Compliance: RoHS, lead-free, halogen-free, aligned with global environmental standards.

Product Use Cases and Benefits to Users

• Robust performance for DC-DC converters, power supplies, LED drivers, and telecommunications applications.
• Compact, low-profile surface-mount form factor simplifies board space and integration.
• Enhanced energy efficiency via low resistance and high saturation margin.
