Eaton, 0703 Shielded Wire-wound SMD Inductor with a Ferrite Core, 10 μH ±20% Wire-Wound 2.47A Idc

dr73-100-r Eaton, 0703 Shielded Wire-wound SMD Inductor with a Ferrite Core, 10 μH ±20% Wire-Wound 2.47A Idc
DR73-100-R
brand logo

HT Part No. HT27334

Mfr. Part No. DR73-100-R

Manufacturer: Eaton

Technical Documents: DR Series High Power Density, High Efficiency, Shielded Inductors Data Sheet-26d92d9c(datasheets) Transition to Bussmann Series-a5d4ae80(datasheets) SPICE Model-3f6bb063(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.36
Units Per Unit Price
5 + £ 0.36
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Inductance 10 μH
Maximum DC Current 2.47A
Package/Case 0703
Length 7.6mm
Depth 7.6mm
Height 3.55mm
Dimensions 7.6 x 7.6 x 3.55mm
Shielded Yes
Tolerance ±20%
Maximum DC Resistance 65.6mΩ
Core Material Ferrite
Maximum Self Resonant Frequency 100kHz
Inductor Construction Wire-Wound
Maximum Operating Temperature +125°C
Minimum Operating Temperature -40°C

More Information

DR73/74/125/127 Series Magnetically Shielded Wire Wound Chokes DR series magnetically shielded drum core inductors with a high power density and a high efficiency. The DR series inductors are designed with a ferrite core, are securely mounted and have a 125°C maximum operating temperature.

Applications for the DR series include: Computers DVD players and portable devices; LCD panels; DC-DC converters; Buck , boost, forward and resonant converters; Noise filtering and filter chokes.
