EPCOS, B82462-G4 Shielded Wire-wound SMD Inductor with a Ferrite Core, 33 μH ±20% Wire-Wound 850mA Idc

b82462g4333m000 EPCOS, B82462-G4 Shielded Wire-wound SMD Inductor with a Ferrite Core, 33 μH ±20% Wire-Wound 850mA Idc
B82462G4333M000
brand logo

HT Part No. HT28349

Mfr. Part No. B82462G4333M000

Manufacturer: EPCOS

Technical Documents: Datasheet-eb9611c4(datasheets)

25 - In Stock pcs
Price:
£ 0.85
Units Per Unit Price
5 - 49 £ 0.85
50 - 249 £ 0.79
250 + £ 0.55
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Inductance 33 μH
Maximum DC Current 850mA
Length 6.3mm
Depth 6.3mm
Height 3mm
Dimensions 6.3 x 6.3 x 3mm
Shielded Yes
Tolerance ±20%
Maximum DC Resistance 230mΩ
Series B82462-G4
Core Material Ferrite
Maximum Self Resonant Frequency 16MHz
Minimum Operating Temperature -55°C
Inductor Construction Wire-Wound
Maximum Operating Temperature +150°C

More Information

B82462-G4 Series Magnetically Shielded Wire Wound Chokes SMT size 6 x 6 mm
Ferrite core construction
Magnetically shielded
Winding enamel copper wire
Wide operating temperature -55°C → +125°C
Suitable for reflow soldering
Applications in filtering of power supplies
