EPCOS, Standard Metal Oxide Varistor 220pF 25A, Clamping 710V, Varistor 430V

B72210S0271K101
brand logo

HT Part No. HT25298

Mfr. Part No. B72210S0271K101

Manufacturer: EPCOS

Technical Documents: Datasheet-a7ebec92(datasheets)

820 - In Stock pcs
Price:
£ 0.20
Units Per Unit Price
20 - 199 £ 0.20
200 - 499 £ 0.17
500 + £ 0.17
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Varistor Voltage 430V
Maximum AC Voltage Rating 275V
Maximum DC Voltage Rating 350V
Clamping Voltage 710V
Clamping Current 25A
Material Metal
Energy 43J
Series Standard
Maximum Surge Current 2500A
Capacitance 220pF
Length 12mm
Depth 14.5mm
Thickness 5mm
Dimensions 12 x 5 x 14.5mm
Lead Pitch 2.2 mm, 7.5mm

More Information

Leaded varistors are varistor elements with lead wires as terminals. The coating of the varistors is made of flame-retardant material. Wide operating voltage range 11 … 1100 VRMS
High surge current ratings up to 8 kA
No derating up to 105 °C ambient temperature
For S14/ S20 types duty cycle @ 6 kV/ 3 kA = >10 pulses, according to IEC 60950-1,
Annex Q, IEC 61051-2
PSpice models
