HT Part No. HT27190
Mfr. Part No. L7905CV
Manufacturer: STMicroelectronics
Technical Documents: Datasheet-be6f67fd(datasheets) ESD Control Selection Guide V1-99dc6d94(datasheets)
| Product Attributes | |
|---|---|
| Maximum Output Current | 1.5A |
| Regulator Type | Linear Voltage |
| Output Voltage | -5 V |
| Number of Outputs | 1 |
| Line Regulation | 100 mV |
| Load Regulation | 100 mV |
| Mounting Type | Through Hole |
| Polarity | Negative |
| Quiescent Current | 3mA |
| Package Type | TO-220 |
| Pin Count | 3 |
| Output Type | Fixed |
| Dimensions | 10.4 x 4.6 x 9.15mm |
| Minimum Operating Temperature | 0 °C |
| Maximum Input Voltage | -35 V |
| Maximum Operating Temperature | +150 °C |
| Height | 9.15mm |
| Width | 4.6mm |
| Length | 10.4mm |
